Auto transformer 45KVA
$3,750.00 – $3,850.00
1 × Transformer Upgrade Nema-3R
Weather Shield Kit (Outdoor use)
NEMA 3R enclosures are designed for both indoor and outdoor use and are specifically built to protect electrical equipment from a variety of environmental hazards. Here are the key features and uses:
$149.00
Product Description
Auto Transformer 45KVA / 240 – 600 V
This Auto Transformer 15KVA and is for general purpose transformer rated 240V to 600V can be utilised for applications rated from 208V-250V to 550V-600V with minimal loss.
IMPORTANT NOTE: Voltage sensitive equipment such as CNC/PLC loads may require voltage stabilizers to bring voltages within range
Features
- Does not require special installation
- Dry type with no liquids to inspect
- May be installed close to the load to reduce wiring runs
- Commonly used for inductive and resistive loads such as motors and heating
For installation in indoor locations with a clean, dust free and chemical – free air circulation. Provides a degree of protection against incidental contact by non-authorized personnel Transformer winding may consist of either aluminum or copper enclosed in a Nema1
Additional information
| Weight | 370 lbs |
|---|---|
| Dimensions | 30 × 25 × 24 in |
| Kilowatts | 45 KVA |
| Voltage Range | 240 V – 480 V, 240 V – 600 V |
| Enclosure | Type 1 |
| Phase | 3 Phase |
| Certification | CSA, ULC |
| Transformer Type | Dry |
| Mounting | Floor mount |
| Specifications | View |
